Synthetic Webbing Sling, ASME/ANSI B30.9
Double Ply Eye & Eye Webbing Sling Class 5
	Webbing  Width (inch)	Vertical	Choker	Vertical  Basket	60 Basket	45 Basket	30 Basket	M.B.S.
		lbs	lbs	lbs	lbs	lbs	lbs	lbs
	1	2,200	1,760	4,400	3,811	3,111	2,200	11,000
	1-1/2	3,300	2,640	6,600	5,716	4,667	3,300	16,500
	1-3/4	3,800	3,040	7,600	6,582	5,374	3,800	19,000
	2	4,400	3,520	8,800	7.621	6,222	4,400	22,000
	3	6,600	5,280	13,200	11,432	9,333	6,600	33,000
	4	8,200	6,560	16,400	14,203	11,595	8,200	41,000
	5	10,200	8,160	20,400	17,667	14,423	10,200	51,000
	6	12,300	9,840	24,600	21,304	17,393	12,300	61,500
Class 5 means rated loads are based on a stuffer weave construction webbing possessing a  minimum certified tensile strength of 6,800 lbs/inch width.
Double Ply Eye & Eye Webbing Sling Class 7
	Webbing  Width (inch)	Vertical	Choker	Vertical  Basket	60 Basket	45 Basket	30 Basket	M.B.S.
		lbs	lbs	lbs	lbs	lbs	lbs	lbs
	1	3,100	2,480	6,200	5,370	4,384	3,100	15,500
	1-1/2	4,700	3,760	9,400	8,141	6,646	4,700	23,500
	1-3/4	5,400	4,320	10,800	9,353	7,636	5,400	27,000
	2	6,200	4,960	12,400	10,739	8,767	6,200	31,000
	3	8,800	7,040	17,600	15,242	12,444	8,800	44,000
	4	11,000	8,800	22,000	19,052	15,554	11,000	55,000
	5	13,700	10,960	27,400	23,729	19,372	13,700	68,500
	6	16,500	13,200	33,000	28,578	23,331	16,500	82,500
	8	22,750	18,200	45,500	39,403	32,169	22,750	113,750
	10	28,400	22,720	56,800	49,189	40,158	28,400	142,000
Class 7 means rated loads are based on a stuffer weave construction webbing possessing a  minimum certified tensile strength of 9,800 lbs/inch width
