Synthetic Endless Round Sling (ASME/ANSI B30.9)
	Vertical	Choker	Vertical  Basket	60 Basket	45 Basket	30 Basket
	lbs	lbs	lbs	lbs	lbs	lbs
	2,600	2,100	5,200	4,500	3,700	2,600
	5,300	4,200	10,600	9,200	7,500	5,300
	8,400	6,700	16,800	14,500	11,900	8,400
	10,600	8,500	21,200	18,400	15,000	10,600
	13,200	10,600	26,400	22,900	18,700	13,200
	16,800	13,400	33,600	29,100	23,800	16,800
	21,200	17,000	42,400	36,700	30,000	21,200
	25,000	20,000	50,000	43,300	35,400	25,000
	31,000	24,800	62,000	53,700	43,800	31,000
	40,000	32,000	80,000	69,300	56,600	40,000
	53,000	42,400	106,000	91,800	74,900	53,000
	66,000	52,800	132,000	114,300	93,300	66,000
	90,000	72,000	180,000	155,900	127,300	90,000
Remarks： •Eye and eye type roundsling is available upon your request.  •When ordering it is important to make clear whether the length specified is circumference  or effective working length.  •Safety factor: 5:1 to ASME/ANSI B.30.9
