Turn Clamp
Type：Lifting Hoist Products - Lifting Clamp Trolley

Turn Clamp

Part No. Model WLL(tonnes) Jaw Opening(mm) Weight(kg)

FD-0099 DFM1 1 0-15 2.7

FD-0100 DFM2 2 0-20 5.6

FD-0101 DFM3 3 0-30 8

FD-0102 DFM5 5 0-60 13.4

DFM turn clamp

Working load limit(WLL)：1-5T

Use：

● For lifting and turn steel plate.

● From a mechanics point of view ,these clamps have ideal designs,which are compact ,
lightweight ,easy to use.

● The main body and parts are made from die-forge special alloy steels, which are optimally

tempered for maximum strength and durability.

● The working load limited is applied in one piece , during lifting single could be in use for
horizontal lifting and transport.
