ASTM80 Standard Link Chain, Transport Chain ASTM80 (G70)
Type：Chain - Welded Link Chain

TRANSPORT CHAIN ASTM80 (G70)

Trade
Size Material
Diameter Working Load
Limit Proof Test Breaking Force
Min Max Length
Per 100 Links Max Weight
Per 100 Feet

IN MM LBS KG LBS KN LBS KN IN M LBS KG

1/4 0.281 7.1 3150 1430 6300 28 12600 56.1 98 2.49 84 38

5/16 0.343 8.7 4700 2130 9400 41.8 18800 83.6 110 2.79 120 54

3/8 0.406 10.3 6600 3000 13200 58.7 26400 117.4 134 3.4 176 80

1/2 0.531 13.5 11300 5130 22600 100.5 45200 201.1 160 4.06 300 136

◇Prev：Snap Hook With Screw, Zinc Plated, Stainless Steel Snap Hook with Screw
◇Next：6x19 Steel Wire Rope (Ungalvanized and Galvanized)

【ASTM80 Standard Link Chain, Transport Chain ASTM80 (G70)】

TRANSPORT CHAIN ASTM80 (G70)
Trade Size	Material Diameter		Working Load Limit		Proof Test		Breaking Force Min		Max Length Per 100 Links		Max Weight Per 100 Feet
Trade Size	IN	MM	LBS	KG	LBS	KN	LBS	KN	IN	M	LBS	KG
1/4	0.281	7.1	3150	1430	6300	28	12600	56.1	98	2.49	84	38
5/16	0.343	8.7	4700	2130	9400	41.8	18800	83.6	110	2.79	120	54
3/8	0.406	10.3	6600	3000	13200	58.7	26400	117.4	134	3.4	176	80
1/2	0.531	13.5	11300	5130	22600	100.5	45200	201.1	160	4.06	300	136
