Phosphorzed Steel Wire for Optical Fibre Cable | |||
Nominal Diameter (mm) |
Nominal Tensile Strength (Mpa) |
Weight of Zinc Coat (g/m²) |
Counting Weight of Wire (kg/100m) |
0.80 | 1370, 1470, 1570, 1670 | >3 | 0.40 |
0.90 | 0.50 | ||
1.00 | 0.62 | ||
1.20 | 0.89 | ||
1.40 | 1.21 | ||
1.50 | 1.39 | ||
1.60 | 1.58 | ||
2.00 | 2.47 | ||
2.20 | 2.99 | ||
2.30 | 3.30 | ||
2.50 | 3.86 | ||
2.60 | 4.17 | ||
2.80 | 4.84 | ||
3.00 | 5.55 | ||
Main applications: suitable for reinforcement of optical fibre cable. |
