DIN 1480 Turnbuckle, Eye & Eye | ||||||||||
Dia. | Permissible Load | Weight | Dimension | |||||||
11 | m | 12 | b | di | da | i | ||||
mm | kg | N | kg/100pcs | mm | mm | mm | mm | mm | mm | mm |
M6 | 230 | 2250 | 7.8 | 110 | 10 | 60 | 53 | 10 | 20 | 4.5 |
M8 | 418 | 4100 | 14.8 | 110 | 14 | 60 | 55 | 12 | 26 | 6.5 |
M10 | 663 | 6500 | 29.4 | 125 | 20 | 65 | 60 | 14 | 30.5 | 8 |
M12 | 948 | 9300 | 36.3 | 125 | 21 | 75 | 70 | 18 | 37.5 | 10.5 |
M16 | 1804 | 17700 | 91 | 170 | 27 | 100 | 90 | 22 | 48 | 13 |
M20 | 2752 | 27000 | 156 | 200 | 34 | 115 | 100 | 25 | 51 | 20 |
M24 | 3996 | 39200 | 325 | 255 | 39 | 140 | 130 | 28 | 66 | 27 |
M30 | 6371 | 62500 | 415 | 255 | 45 | 145 | 130 | 35 | 83 | 31 |
1-1/4" | 6585 | 64600 | 595 | 295 | 55 | 160 | 150 | 36.5 | 88 | 33 |
M36 | 9276 | 91000 | 745 | 295 | 55 | 160 | 150 | 44 | 104 | 40 |
1-1/2" | 9572 | 93900 | 1076 | 330 | 63 | 185 | 170 | 42 | 104 | 49 |
Please noted: the size of the body is same for the eye and hook, hook and eye, hook and hook. Turnbuckle DIN 1480 Eye & Eye - Rigging Hardware •Material: Mild Steel or Cast Steel or Carbon Steel. •Made by Forged or Cast •Finished: Galv. self-color or Hot Dipped Galv. •Packing: Gunny bags or Cartons and then on pallets. (customer are avaiable) •Feature: Two Kinds Made, Cast and Forged. Forged with an advance quantity, Cast with a cheaper price •Advantage: widely used, easy handling for tightening. •Benifit:Save working time, correct tool |
